Nominal Input Level: -10 or -4 dBv
Input Impedance: 1.8M ohms
Bandwidth: +0 / -3 dB 20 – 20k Hz
Gain Range: 0 – 15 dB (makeup)
Compression Ratio: min / max1:1 -5:1
Sensitivity Range (Threshold): -25 – +6 dB
Attack Time (80%)
Release Time (80%): typ. 100 ms
Dimensions (L x W x H): 67 x 115 x 48 mm( 2.6” x 4.5” x 1.9” )
Weight: 315g (0.7 lb.)
Bypass: True Bypass (Relay type Switching)
Power Requirements: 9V – 18V DC Regulated,
DC 45 mA max
